Fuel Surge Tank for internal fuel pumps includes:
1 x 3.0 liter fuel surge tank
1 x 6 bolt pattern aluminum mounting bracket
6 x AN-8 (3/4 UNF) to AN-8 Male fittings
2 x AN-8 (3/4 UNF) Plugs
1 x Tripple mounting bracket for 39mm fuel pumps
3 x 1/4 BSPP to 8mm Barb (fuel hose) fittings
Fuel Surge Tank Specifications
Length 265mm
FST diameter Ø 148mm
Bracket diameter Ø 178mm
Mounting points 6 x M6 (Ø 6.5 mm / 0.25″)
Weight 2880g
Outlet thread AN-8
Inlet thread AN-8
Return thread AN-8
