Ecumaster PMU 16 Autosport Version
Ecumaster PMU 16 Autosport Version
Ecumaster PMU 16 Autosport Version
SPECIFICATION
Temperature range – AECQ100 GRADE1 (-40 to +125˚C)
CPU – 32 bits automotive. 90MIPS
Reverse polarity protection – Yes. internal
Operating voltage – 6-22V. immunity to transients according to ISO 7637
Enclosure – IP65. bespoke CNC machined aluminium
Size (mm) and weight (g) – 177x84x46.1. 360g
Connectors – 1 x AS shell size 24. 19 x 12AWG 1 x AS shell size 14. 37 x 22AWG 1 x RADLOK 10mm battery terminal
PC communication – CAN (ECUMASTER USBtoCAN. PEAK CAN. KVASER)
OUTPUTS
High current outputs – 14x25A(cont.). 2x40A(cont.) with overcurrent and overheating protection. Outputs may be paired to increase continuous current capability. Current and voltage is measured for each output
Low side outputs – 6 x 1A (13A peak) with overload thermal shutdown
Total current output – 200A continuous
Output current control step – 100mA
Wipers output – Dedicated output with wiper braking feature
+5V – Monitored 5V. 500mA output for powering external sensors.
INPUTS
Analog inputs – 16 inputs. 10 bit resolution. 0-5V (protected). with software selectable 10K Ohm pullup and pulldowns
CAN Keypads – 2 x Ecumaster keypads (4. 6. 8. 12 keys). 1 x MoTeC/RaceGrade. 1 x Grayhill
OTHER
Output state indication – 16 bicolour LEDs
Accelerometer/Gyroscope – 3D accelerometer with 3D gyroscope for logging and crash detection
Real time clock – Yes. super capacitor for backup power (up to 3 days)
CAN BUS
CAN interface – 2 x CAN 2.0 A/B (125. 250. 500. 1000 kbps)
Input/output stream – User defined with bit masking up to 100 input messages
LOGGING
Logging memory – 256 Mbytes (3 hours of logging at maximum bandwidth)
Logging speed – Variable. defined per channel. up to 500Hz
Logging to PC – Yes
FUNCTIONS
Logical operators – AND. OR. NOT. XOR. >. <. =. >=. <=. !=. isTrue. isFalse. Toggle. Flash. Pulse
Number of functions – 100
Number of operations – 250
Update frequency – 500Hz
Special functions – Wipers. indicators
2,135,00 € *Sisaldab KM
