G4X PlugIn Key Features (where applicable):
- Up to 6D fuel and ignition mapping
- Precision closed loop cam control (four cam, independent control)
- Sequential fuel delivery
- Digital triggering, all OEM patterns
- OEM idle hardware supported
- 5D boost control with three switchable tables
- Motorsport features — antilag, launch, flat shift
- Continuous barometric correction (on board)
- CAN port
- QuickTune — automated fuel tuning
- Individual cylinder correction
- USB tuning cable included
- Stats recording into on-board memory
- Gear compensations for spark, boost and fuel
- Real time selectable dual fuel, ignition and boost maps
- Sync and crank sensors can be a combination of Hall effect, variable reluctance or optical
- Boost control referenced to gear, speed or throttle position
- 512 mega bytes data logging memory
- Staged injection
- Knock with «windowing»
I/O Expansion Options:
The following expansion connector inputs/outputs are provided:
Expansion connector 1
Gnd Sensor Ground Only
+5V Low Current +5V Supply
Aux 15 Auxiliary Output
Aux 14 Auxiliary Output
DI 8 Digital Input
DI 9 Digital Input
An Volt 8 Analog 0-5V input
Expansion connector 2
An Temp 4 Temperature sensor input
DI 11 Digital Input
Aux 16 Auxiliary Output
Aux 8 Auxiliary Output
+5V Low Current +5V Supply
Gnd Sensor Ground Only
Click here to download the full Specifications PDF.
